Depth: 1236mm
Width: 1500mm
Height: 2300mm

Square meters: 1.8m²

Depth: 1200mm
Width: 1340mm
Height: 2140mm

Our pods have an area of 60% covered polyester fiber sound-absorbing material. They follow the standard for environmental classification.
Design value: Rw + Ctr 30 dB (+5 dB) and RT0.75 s (+ 0.1 s).

Based on non-vulcanized butyl rubber, covered with self-adhesive PE adhesive fabric surface, the modular felt material is moisture resistant, anti-mold, easy to clean and maintain. Our material selection combined with design adjustment has enabled us to find the best relationship for sound absorption, noise, and vibration insulation.

The pods use double pane glass for the desired noise reduction performance.

The surface of our insulation panel is covered with a Korean-made nanometer PP facing, which has high resistance to friction, ultraviolet rays, fire, and moisture.

We have provided the pods with a cable hole on the outside if data and power transmission are needed. The hole can be closed when it is not needed to avoid sound flanking.

Our bottom panel is equipped with our own damper block for better vibration and structural cage noise.

Air ventilation system with a maze-like interior layout to ensure the necessary air circulation in three minutes while preserving the sound insulation properties of the pods.

Our pods are equipped with 12 V-USB power supply and are rated for 100-220V / 50HZ which meets the usual equipment requirements. Possibility to choose a different power supply is possible.

Our pods are equipped with a 4000 K daylight color temperature LED lighting system (150 LX) which meets the needs for normal activities. In the event of additional power requirements, there is a reserve power supply inside the pod.

Only one type of fastener is used for installation, which makes the installation of our booths easier. We also have clear installation videos that clearly show how everything is supposed to be assembled.
